Turbosmart Fuel Pressure Regulators – FPR12
Included:
Fuel Pressure Regulator
Mounting bracket
2 x M5 Mounting Screws
Turbosmart Decal
Features
12AN Inlet & Return
4 x 10AN Fuel Distribution
Stainless Steel Valve Seat
Suitable for all fuel types
1:1 Class Leading Ratio & Response
Adjustable Pressure
1/8 NPT Pressure Sensor Port
Unique Locking Collar Design
Milspec Diaphragm
Suits Up to 3000HP Systems.
The Turbosmart FPR Pro 12 Series provides market leading fuel control and response via true 1:1 ratio and superior flow and bypass capacity for vehicles with -12 / 12AN fuel feed and -12 / 12AN return fittings. Utilising our Stainless Steel Valve Seat & Milspec Diaphragm the FPR12 Pro Series is suitable for all Fuel types including Race Fuel and aggressive leaded fuels. Our FPR12 Pro Range includes 1 x 12AN inlet, 4 x 10AN outlet ports and a 12AN return and is available in Pro EFI (50psi to 130psi) and Pro M (50psi to 100psi) for Mechanical Pump Systems.
